Agricultural Axle With Brake or Without Brake Light Loading Trailer
Axle
Trailer Axle Parameters
Capacity
(T) | Track
(mm) | Axle Beam
(mm) | Brake lever
position(mm) | Brake Spec.(mm) | Wheel Fixing(mm) | Bearing | Weight(Kg) |
1 | 1600 | ¨40 | no | no | 4×M14×φ130×84 | 30205-20207 | 35 |
1.5 | 1600 | ¨45/○45 | no | no | 6×1/2"×φ139.7 | LM68149/10
LM12749/10 |
|
2 | 1600 | ¨50/○50 | no | no | 6×1/2"×φ139.7 | 25580/20
15123/15245 |
|
3 | 1600 | ¨50 | 470 | 255×60 | 6×M18×φ205×160 | 30206-30209 | 65 |
5 | 1600 | ¨60 | no | no | 6×M18×φ205×160 | 30207-30211 | 60 |
5 | 1600 | ¨60 | 470 | 255×60 | 6×M18×φ205×160 | 30208-30211 | 100 |
6 | 1600 | ¨70 | no | no | 6×M18×φ205×160 | 30208-30213 | 85 |
6 | 1600 | ¨70 | 470 | 300×60 | 6×M18×φ205×160 | 30208-30213 | 120 |
The track can be customized according to customer's request. |
Trailer Axle Introduction
Chongqing Xianyou Technlogy Development Co. Ltd. is the
professional manufacturer of axles. We have been devoted to
development, design and manufacture axle and semi trailer products
since 1998. Trailer Axles are available in different lengths and
hub faces. Coated with standard black paint. Axle seats and lug
nuts come loose with axle. Axle seats and lug nuts come loose with
axle. Trailer axle assembly contains trailer axle beam with pressed
in spindles and four bolt mount brake flange, hubs (races pressed),
bearings, grease cap, and grease seal, axle seats, and lug nuts.
Trailer Axle More Pictures
Trailer Axle Packing
Tralier axle can be packed by can be packed by felt, pallet,
felt+pallet, felt+wooden box or any other packing as per your
requirements. Trailer axle usually chooses containerized sea
shipping in quantity delivery or air delivery in sample orders.
Trailer Axle Installation
FAQ
1. Are you manufacturer?
Yes. We are one of leading manufacturers in axle
design&development.
2. Do you have stock products to sell?
Yes, a few. And we also offer OEM&ODM service. Please send us
your drawing.
3. What information needed to get axle quotation?
a). Trailer max loading.
b). Pictures of your axle from different views.
c). Packing&Shipping requirements.
d). Quantity needed.
4. Do you inspect the finished products?
Yes. Each step of production will be carried out inspection by QC
department until finishing.
